Khoom Taw Qhia
6L ultrasonic qhov chaw nqus tsev ntxhua khaub ncaws yog nruab nrog 2 pcs siab -kev ua tau zoo 60W 40KHz ultrasonic transducers, ua rau 120W ntawm lub zog tu ultrasonic muaj zog. Vim lub zog ceev no tau hloov mus rau 6-litre tank, lub ultrasonic tuaj yeem nkag mus rau hauv qhov nyuaj- mus rau- mus txog thaj chaw sai, uas ua rau lub tshuab nqus dej kom tshem tawm cov av ntawm qhov chaw thiab qhov chaw ntawm qhov chaw zoo. Tsis tas li ntawd, nws muaj lub zog ua kom muaj zog 260W cua sov ua haujlwm nrog qhov kub ntawm 20-80 degree, uas tuaj yeem ua kom sov sai rau qhov ntsuas kub hauv lub sijhawm luv luv.
6L ultrasonic qhov chaw ntxhua khaub ncaws muaj SUS304 ultrasonic tu tank, uas muaj corrosion kuj zoo heev thiab tshwj xeeb toughness. Nws tuaj yeem tiv taus kev yaig ntawm ntau yam tshuaj ntxuav hauv cov roj hnyav yam tsis muaj kev puas tsuaj lossis kev laus, yog li ncua lub neej ntawm lub tshuab.
Khoom siv: SUS304 nrog cov phab ntsa tuab thiab cov qauv muaj zog
Peev xwm: 6 liters
Lub tank loj: 300 (L) X 150 (W) X 150 (H) mm
Qhov loj me no yooj yim haum rau feem ntau me me thiab nruab nrab- qhov loj me siv txhua hnub. Nws boasts zoo adaptability, txhawb ib qho loj los yog me me tu los yog batch tu ntawm ntau yam me me, thiab yog sib xws nrog ntau yam workpieces xws li automotive roj injectors, PCB boards, kho hniav instruments, hardware bearings, screws, thiab bolts.
Technical Specification
| Product Description | 6L Ultrasonic Parts Cleaner |
|
Qauv No.: |
SE-6000B |
|
Ultrasonic zaus |
40 kHz |
|
Qhov hluav taws xob |
100-120V 60Hz / 220-240V 50/60Hz |
|
Lub zog: |
380W |
|
Lub sijhawm ntxuav |
5-30 feeb |
|
Muaj peev xwm |
6 litr |
Product Advantage
6L Sonic nqus tsev vacuum rau qhov chaw muaj qhov zoo hauv qab no:
- - Core Functions: Nruab nrog dual- lub zog degassing hom, nws tshem tawm cov npuas npuas hauv cov kua dej huv, txhim kho kev ua haujlwm zoo hauv qhov muag tsis pom kev, crevices, thiab lwm yam nyuaj - mus rau - mus txog thaj chaw, nce kev ua tau zoo ntawm 30%; txhawb 0-99 feeb timer tswj; thiab nta lub tshuab hluav taws xob / digital dual tswj vaj huam sib luag rau kev ua haujlwm yooj yim thiab meej, yoog raws lub sijhawm tu lub sijhawm ntawm cov khoom sib txawv.
- - Kev nyab xeeb thiab kav ntev: Ua tau- nyob rau hauv kev tiv thaiv triple nrog rau qhib- npog lub hwj chim- tawm kev tiv thaiv, tiv thaiv overheat, thiab kev tiv thaiv overload; Kev khiav hauj lwm suab nrov tsawg dua los yog sib npaug rau 75dB, ua tau raws li cov qauv kev ua haujlwm ib puag ncig; transducer lifespan tshaj 5000 teev; tag nrho lub tshuab siv lub rooj tsav xwm hloov pauv hloov pauv, uas ua rau muaj kev ruaj ntseg zoo dua thiab txo nqi txij nkawm.
Cov khoom siv
Lub 6-liter sonic nqus tsev ntxhua khaub ncaws tuaj yeem siv rau cov hauv qab no:
Cov tsheb kauj vab: xws li cov saw tsheb kauj vab
Cav qhov chaw
Phom qhov chaw
PCB
Kev Pabcuam OEM
Peb yog cov chaw tsim khoom tshwj xeeb hauv cov khoom siv ultrasonic, los ntawm piezoelectric transducers mus rau ultrasonic ntxuav. Nrog rau kev ua tiav hauv - cov saw hlau tsim khoom hauv tsev, peb muaj peev xwm ua tau raws li tag nrho koj cov kev pabcuam OEM xav tau nrog cov kws tshaj lij.
Peb tuaj yeem muab kev pabcuam OEM rau koj Qhov Zoo Tshaj 6L ultrasonic nqus tsev vacuum rau qhov chaw; peb tuaj yeem muab cov kev pabcuam hauv qab no rau koj:
- Cov khoom tshwj xeeb xim
- Cov khoom tsim tshwj xeeb logo tsim: peb tuaj yeem kho koj tus ID khoom rau hauv cov khoom siv, xws li koj lub logo thiab koj tus kheej tsim xim thawv.
- Peb tuaj yeem muab koj cov ntaub ntawv OEM xws li Ultrasonic zaus, lub zog ultrasonic thiab lub zog cua sov
Hauv qab no yog tus qauv ultrasonic tu transducer muaj rau koj xaiv.
Yog tias tsis muaj ib qho kev qhia tshwj xeeb ua tau raws li koj cov kev xav tau, tsuas yog qhia rau peb paub koj cov khoom siv zoo tshaj plaws. Peb tuaj yeem ua kev cai loj piezoelectric ceramic rings rau ultrasonic tu raws li koj cov lus qhia meej.
Tsuas yog muab peb cov ntsiab lus xws li qhov loj ntawm koj lub tank tu ultrasonic, thiab peb yuav muab cov kev daws teeb meem. Qhov no yuav suav nrog tus naj npawb zoo ntawm cov transducers, qib fais fab tsim nyog, thiab -qhov tseem ceeb tshaj - qhov sib piv ultrasonic zaus.
|
Kev faib tawm |
Qauv |
Fkev xav tau (KHz) |
ReLub impedance (Ω) |
Static Capacitance (PF) |
Insulation Resistance (MΩ) |
Ptus tswv (W) |
|
Ultrasonic Ntxuav Series |
Q120W-20K |
20±1 |
Tsawg dua los yog sib npaug li 20 |
4800±10% |
Ntau dua los yog sib npaug rau 100 |
120W |
|
Q100W-28K/40K |
28±/40±1 |
Tsawg dua los yog sib npaug li 20 |
8000±10% |
Ntau dua los yog sib npaug rau 100 |
100W |
|
|
Q80W-28K/40K |
28±/40±1 |
Tsawg dua los yog sib npaug li 20 |
7000±10% |
Ntau dua los yog sib npaug rau 100 |
80W |
|
|
Q60W-28K/40K |
28±/40±1 |
Tsawg dua los yog sib npaug li 20 |
5000±10% |
Ntau dua los yog sib npaug rau 100 |
60W |
|
|
Q60W-68K |
68±1 |
Tsawg dua los yog sib npaug li 20 |
3800±10% |
Ntau dua los yog sib npaug rau 100 |
60W |
|
|
Q60W-120K |
120±1 |
Tsawg dua los yog sib npaug li 20 |
3800±10% |
Ntau dua los yog sib npaug rau 100 |
60W |
|
|
Q50W-40K |
40±1 |
Tsawg dua los yog sib npaug li 20 |
4000±10% |
Ntau dua los yog sib npaug rau 100 |
50W |
|
|
Q40W-40K |
40±1 |
Tsawg dua los yog sib npaug li 30 |
3000±10% |
Ntau dua los yog sib npaug rau 100 |
40W |
|
|
Q30W-40K |
40±1 |
Tsawg dua los yog sib npaug li 30 |
1800±10% |
Ntau dua los yog sib npaug rau 100 |
30W |
|
|
Q15W-50K |
50±1 |
Tsawg dua los yog sib npaug li 100 |
1100±10% |
Ntau dua los yog sib npaug rau 100 |
15W |
FAQ
Q: Dab tsi yog qhov ntsuas kub zoo tshaj plaws rau 6L ultrasonic tu?
A: Qhov ntsuas kub zoo tshaj plaws rau 6L ultrasonic nqus tsev vacuum rau qhov chaw yog 20-80 degree, vim hais tias lub luag haujlwm tseem ceeb ntawm cov cua sov yog los pab tus neeg saib xyuas kom tshem tawm cov av ntawm qhov chaw tu, yog li qhov kub yuav tsum phim tus yam ntxwv ntawm tus neeg saib xyuas. Qhov ntau ntawm cov cua sov tuaj yeem pab teeb tsa qhov zoo tagnrho raws li chav tsev kub. Nws yuav xav tau qhov kub thiab txias ntau dua los them rau qhov poob cua sov thaum chav tsev kub qis dua, tshwj xeeb tshaj yog nyob rau lub caij ntuj no.
Q: Yuav ua li cas ntxuav lub cav kom zoo nrog 6L sonic nqus tsev ntxhua khaub ncaws?
A: Ua ntej, koj yuav tsum xyuas kom meej tias cov khoom tuaj yeem muab tso rau hauv dej kom huv si, thiab qhov tseem ceeb tshaj, cov khoom yuav tsum muab tso rau hauv lub pob tawb kom cov khoom dai hauv dej.
Qhov thib ob, koj yuav tsum xaiv tus neeg saib xyuas txoj cai. Koj paub, muaj roj hnyav ntawm cov khoom, uas tuaj yeem tshem tawm sai sai nrog kev pab los ntawm tus neeg saib xyuas tu.
Thib peb, koj yuav tsum tau ua tib zoo nyeem qhov ntsuas kub zoo tshaj plaws rau tus neeg saib xyuas huv.
Lub 6L ultrasonic nqus tsev vacuum rau qhov chaw yog siv cov nyhuv cavitation los ntxuav qhov nyuaj - mus rau - mus txog thaj chaw, uas yog txoj kev tu lub cev; nws yuav zoo dua nyob rau hauv kev pab los ntawm tus neeg saib xyuas tu.
Q: Vim li cas kuv 6L ultrasonic nqus tsev vacuum rau qhov chaw tsis tu kom zoo?
A: Thov xyuas nrog koj 6L ultrasonic nqus tsev vacuum rau qhov chaw seb nws puas muaj suab nrov; yog tsis yog, nws txhais tau tias koj lub tshuab tuag. Qhov teeb meem yuav tsis muaj nuj nqi kiag li.
Ntawm qhov tod tes, peb yuav tsum nkag siab tias kev tu ultrasonic yog ib txoj hauv kev los ntxuav lub cev tab sis tsis yog tshuaj lom neeg uas tuaj yeem ua rau lub ntsej muag ntawm cov khoom thiab tig nws ci txhua.
Cim npe nrov: Tuam Tshoj 6L ultrasonic qhov chaw nqus tsev vacuum manufacturers, lwm tus neeg, Hoobkas
